50A, 3-WIRE RANGE RECEPTACLE, FLUSH MOUNT, WHITE

  • Product Code:

    FMR1050R-WH
  • Stock Code:

    0276-8268

The RPP-USA FMR1050R-WH 50A, 3-Wire Range Receptacle offers a robust solution for high-demand electrical appliances in both residential and commercial environments. With a flush mount design and a NEMA 10-50R rating, this receptacle ensures compatibility with standard range cords and enhances safety by sitting flush against the wall. Constructed from durable plastic, it is designed to withstand regular use while maintaining structural integrity. Ideal for kitchens, utility rooms, and workshops, this product combines functionality with a sleek, white finish to complement any decor.

Features

  • NEMA Rating 10-50R
  • 1 Phase
  • Wire Size #4-#10AWG
  • Start a Project

    Product

    FMR1050R-WH
    0276-8268
    The RPP-USA FMR1050R-WH 50A, 3-Wire Range Receptacle offers a robust solution for high-demand electrical appliances in both residential and commercial environments. With a flush mount design and a NEMA 10-50R rating, this receptacle ensures compatibility with standard range cords and enhances safety by sitting flush against the wall. Constructed from durable plastic, it is designed to withstand regular use while maintaining structural integrity. Ideal for kitchens, utility rooms, and workshops, this product combines functionality with a sleek, white finish to complement any decor.

    Specifications

    Amperage Rating 50 Amperes
    Color Black
    Connection Screw/Back
    Material Plastic
    Mounting Flush Mount
    Number Of Poles 3 Pole
    Number Of Wires 3 Wire
    Type Electrical Receptacles
    Voltage Rating 125/250 VAC

    Ordering

    Weight0.338 Pounds
    DimensionsL: 62.4 mm    W: 56.8 mm    H: 93.8 mm
    Box Quantity--
    Carton Quantity--
